GL11-016-100

{/if}

price:

$14.20

number:

GL11-016-100

Lead time:

In Stock

quantity:

Download product related materials（Gray indicates that there is no such file，Unable to download） :

GL11-016-100

Diameter (mm)16.00

EFL(mm)100.00

BFL(mm)98.62

R1(mm)51.64

Central Thickness(mm)2.10

Te(mm)1.48

CoatingUncoated

MaterialH-K9L

Compatible lens ringPN35028-LM160-S

Design wavelength587.6nm

Dia. Tolerance(mm)+0.0/-0.1

CT tolerance±0.2

Surface irregularityλ/4@632.8nm

EFL tolerance±2%

Centration3′

Surface quality60/40

Bevel0.2mmX45°

RoHSCompliant
